1600 degree Czochralski Crystal Growth Furnace CHY-1600-SCB

The CHY-1600-SCB vertical Bridgman pulling method crystal growth furnace, with a pulling rod that can rotate itself while lifting, can be suitable for various crystal material growth processes. The multifunctional crystal growth furnace is designed with a total temperature zone, allowing users to grow crystals using the natural gradient distribution of temperature inside the furnace. The equipment is very simple and easy to use. The temperature control part adopts a high-precision temperature control meter from Xiamen Yudian, with a temperature control accuracy of ± 0.1 ℃. The lifting transmission mechanism adopts a high-performance servo motor, making the stroke more stable. This equipment can meet the needs of users to grow high-quality crystals.

Model No.	CHY-1600-SCB
Heating Zone Length	300mm
Max Working Temper	1650 degree
Thermocouple	B type
Temperature Accuracy	+/-1 degree
Temper Control	PID programmable control
Heating rate	Suggest:10℃/Min
Heating Element	MoSi2
Dipping speed	0.1～100mm/h
Rotating speed	0.1～100r/min
Power Supply	AC220/50Hz
Dipping distance	300mm
Rated Power	4.5KW
