500 degree Vacuum Hot Hydraulic Press CHY-PZST

Share:
Application

CHY-PZST is a 25T vacuum hot lamination hot press designed for wafer bonding, thin-film transformations, and LCP lamination with heating area 100 mm x 100 mm or 300 mm x 300 mm. It has the max. the working temperature of 500 ºC along with the max. the pressure of  20-40 Metric Tons.

Product parameters
Model No.CHY-PZST
Pressure
0-25T
Pressing MethodProgram Pressing-Hold-Release
Holding Time0-999.59min.second
Heating temperatureMax 500℃
Heating plate size180*180mm;200*200mm
Chamber MaterialSUS304
Chamber Size780*650*700mm
Trans Chamber SizeΦ240*260mm
Vacuum degree-0.1MPa
Dimension
1200*950*1800mm
Power supply220V/50Hz
