PMH-PEEK is a 200℃ heatable PEEK electrochemical test cell specifically designed for advanced battery and materials research. Engineered from PEEK (Polyether Ether Ketone) — a high-performance engineering plastic with exceptional chemical resistance and thermal stability — this cell enables reliable electrochemical testing under elevated temperatures up to 200℃.
Ideal for use with lithium-ion batteries, solid-state electrolytes, and other energy storage materials, the PMH-PEEK cell provides a sealed, corrosion-resistant environment for precise measurements using standard potentiostats and electrochemical workstations. Its integrated heating design ensures uniform temperature distribution across the sample, making it an indispensable tool for researchers investigating temperature-dependent electrochemical behavior.
| Instrument Model | PMH-PEEK |
| Pressed Sample Shape |  |
| Heating Temperature | RT–100°C |
| Mold Material | PEEK insulating material, suitable for battery testing |
| Indenter Hardness | HRC60–HRC62 |
| Sample Diameter | Φ10, Φ13, Φ15, Φ20, Φ30, Φ40 mm (M) |
| Cavity Depth | 40 mm (N) |
| Overall Dimensions | Φ78 × 138 mm, Φ90 × 138 mm (L × H) |
| Power Supply / Power | 220 V / 500 W |
| Mold Weight | 2.1 kg |
