  • YXQM Series Laboratory Nano Scale Planetary Ball Mill

YXQM Series Laboratory Nano Scale Planetary Ball Mill

1. Short grinding time, fine discharge particle size, and high accuracy;

2. High consistency of repeated grinding;

3. A wide range of materials can be selected for ball milling tanks, with a variety of grindable materials;

4. Four working positions, capable of grinding up to four different types and qualities of materials each time;

5. Under the same conditions, the accuracy consistency of each batch of each jar grinding sample is high;

6. It has many functions such as reverse, forward and reverse alternating operation, stepless speed regulation, timing, intermittent operation, safety protection, power failure memory, data storage, etc;


Share:
Application

This series of grinding mill can be equipped with vacuum jars, which can grind samples in a vacuum state. It is very suitable for research tasks such as scientific research institutions, universities, and corporate laboratories from the experimental end to the production end to verify the feasibility of mass production, as well as routine tasks such as mixing and homogenizing soft, hard, brittle or fibrous materials.

Product parameters
ApplicationsCrushing, mixing, homogenizing, colloid grinding, mechanical alloying, mechanochemistry
Field of applicationNew energy, geology/metallurgy, glass/ceramics, engineering/electronics, building materials, environment/recycling, agriculture, chemistry, medicine, biology
Feed materialSoft, hard, brittle, fibrous—dry or wet
Size reduction principleImpact force, friction
Material Feed Size< 5 mm soil<10 mm
Final Fineness *Used for colloid grinding, the sample is less than 0.1 micron
No. of Grinding Stations4
Grinding methodCan be dry grinding, wet grinding, vacuum grinding, atmosphere protection grinding
Grinding jar materialStainless steel, carbide, zirconium oxide, aluminum oxide, silicon carbide, silicon nitride, polyurethane, nylon, polytetrafluoroethylene, agate
Speed ratio1 : 2
Operation Mode3 types: unidirectional, alternating forward and reverse, multi-stage
Storable SOPs15
Time settingRun/stop time: 0-9999 minutes
Power protectionPower-off protection memory self-start function
ModelYXQM-0.4L                                               YXQM-1L                                                                                     YXQM-2L                                                                     YXQM-4L
Grinding jar capacity50-100ml50-250ml50-500ml50-1000ml
Vacuum jar capacity50ml50-100ml50-250ml50-500ml
Revolution speed5-450r/min5-450r/min5-400r/min5-400r/min
Rotation speed10-900r/min10-900r/min10-800r/min10-800r/min
Power0.55KW0.55KW0.75KW0.75KW
Voltage220V/50Hz 220V/50Hz 220V/50Hz220V/50Hz
Weight68kg70kg96kg99kg
Affected by sample material properties and instrument configuration/settings
