  • J1520 1500 degree Vertical Muffle Furnace

J1520 1500 degree Vertical Muffle Furnace

1.200*200*200mm chamber dimension

2.Customized muffle furnace uses high quality ceramic fiber chamber

3.PID Programmable controller

4.Heavy duty double layer structure

5.The laboratory muffle furnaces could be customized.



Share:
Application

1.laboratory heat thermal processing cement, building materials industry etc

2.Pharmaceutical medicines inspection, preteatment of medical sample

3.Analytical Chemistry Industry: water analysis and environmental analysis

4.Laboratory Gemstone,Crystal Growthing


Product parameters
ModelCHY-J1520
Furnace DoorTop open type
Display ModelHighlight LED display
Maximum Temperature1450℃
Working Temperature≤1350℃
Heating rate≤20℃/min  Suggest:10℃/min
Heating zonesSingle heating zone
Hearth dimensions200mm×200mm×200mm
Hearth volume8L
Control modeIntelligent PID auto control
Temperature Accuracy±1℃
Temperature curve30 segments programmable
Over heat alarmHave
Overcurrent protectionHave
Thermocouple Failure ProtectionHave
Temperature SensorS-type thermocouple
Heating ElementSiC heater
Hearth Materialhigh purity alumina fiber
Power Supply220V  50HZ
Rated power3.5kw
AccessoriesPlate,Protective Glove,Crucible Tong,Crucible,User Manual.
