Jaw crusher use of two jaw plate extrusion and bending of materials, coarse or medium crushing of various hardness materials crushing machinery in the laboratory crusher belongs to the front section of material processing equipment, is one of the essential processing in the crushing stage, the process is simple and easy to use, the jaw plate is simple and adjustable, the adjustment process can be intuitively displayed on the display screen jaw plate spacing, convenient for operators to grasp the sample diameter discharge diameter. Suitable for materials with diameter less than 30mm. After crushing, the material can be adjusted between about 1-13mm. Solve high purity sample pretreatment process.
Jaw crusher belongs to one of the many crushers, mainly used in a variety of ores, metallurgy, mining, chemical industry, building materials, refractory materials, ceramics, environmental protection, materials, biology, etc., mainly by the movable jaw plate periodic pressure to the fixed jaw plate, will be squeezed in the material crushed, to obtain the most fine 1mm material.
| Model | MT-10S | MT-10M | MT-10Y | MT-10T |
| Material of board | corundum | Manganese steel | zirconia | Tungsten carbide |
| Feed port size | 100*70mm | |||
| Feed size | ≤30mm | |||
| Spacing of board | 1-13mm | |||
| Throughput | 1-300kg/h | |||
| Power | 0.75kw | |||
| Weight | 95kg | |||
| Dimension | 500*600*600mm | |||
| Crushing hardness | ≤ Mohs 5.0 | ≤ Mohs 7.0 | ≤ Mohs 7.5 | ≤ Mohs 9.0 |
