  • CHY-M1215 Laboratory Box Type 1200 degree 4.5L Muffle Furnace
  • CHY-M1215 Laboratory Box Type 1200 degree 4.5L Muffle Furnace
  • CHY-M1215 Laboratory Box Type 1200 degree 4.5L Muffle Furnace

CHY-M1215 Laboratory Box Type 1200 degree 4.5L Muffle Furnace

1.150*150*200mm chamber dimension

2.high quality ceramic fiber chamber

3.PID Programmable controller

4.Heavy duty double layer structure

5.Made by Henan Chengyi

Share:
Application

1.laboratory heat thermal processing cement, building materials industry etc

2.Pharmaceutical medicines inspection, preteatment of medical sample

3.Analytical Chemistry Industry: water analysis and environmental analysis

4.Analysis of coal quality,determine moisture, ash, volatile matter, ash melting point analysis, gray component analysis, and elemental analysis


Product parameters
1Product Name1200 Degree Muffle Furnace
2ModelM1215
3Furnace Doorside open type
4Display ModelHighlight LED display
5Maximum Temperature1150℃
6Working Temperature≤1100℃
7Heating rate≤20℃/min  Suggest:10℃/min
8Heating zonesSingle heating zone
9Hearth dimensions150mm×150mm×200mm
10Hearth volume4.5L
11Control modeIntelligent PID auto control
12Temperature Accuracy±1℃
13Temperature curve30 segments programmable
14Over heat alarmHave
15Overcurrent protectionHave
16Thermocouple Failure ProtectionHave
17Temperature SensorK-type thermocouple
18Heating ElementFe-Cr-Al Alloy doped by Mo
19Hearth Materialhigh purity alumina fiber
20After-sales service12 month warranty, durable maintaince and repair support
21Power Supply220V  50HZ
22Rated power1.8kw
23Overall dimensions390×600×430 (mm )
24Packing3-ply wooden case
25AccessoriesPlate,Protective Glove,Crucible Tong,Crucible,User Manual.
